PT 5-2.2 CNC Punching machine

PT 5-2.2 CNC Punching machine with 5 hydraulic units for punching with deformation on stainless steel round tubes. The machine is equipped with two motorized axes and is able to achieve round holes with deformation, on one or two sides of the tube, to accomplish blind or through holes at each stroke.

Specifications

The machine is equipped with two motorized axes and is able to achieve round holes with deformation, on one or two sides of the tube, to accomplish blind or through holes at each stroke.

The automatic gripper can be rotated 360 ° tube (C-axis).

A camera is mounted, to recognize the internal tube welding.
